FALSE CEILING / ACOUSTIC WOOD CEILING 4FOR

The adaptable solution to each situation. Two sizes, three different methods of mounting the elements, multiple drilling schemes, as well as numerous surface finishes, allow the 60x60/120 modular system to adapt to every architectural situation and functional application.

The exterior structure of the building is no longer conceived as a static delimitation element, but as an integrated technological and functional component. In this area, ceilings and walls also acquire a series of functions suitable for guaranteeing the comfort and practicality of the premises. The flexibility of the 60x60/120 modular system resolves acoustic disturbance situations that can occur in different environments such as offices, public spaces or school classrooms, adapting to any layout and use.

The coating system is available with fire reaction class “B-s1,d0” according to the current Eurocode and CE marking for construction materials.

Steps and holes.

The panels are supplied with holes aligned with each other, while the slats with staggered holes, only the P8-1.2a slat has aligned holes. The number following the "P" in the product name represents the pitch, or the distance between the holes. The second number represents the diameter. The "a" indicates aligned holes and the "s" indicates staggered holes.

We have 5 types of 4For Systems:

1- 4for P16-3a / P16-3s

The ideal aesthetic compromise in those spaces where there are large
surfaces and we want to highlight the acoustic liveliness that accompanies them. The percentage of perforations is 2.3%.

2- 4for P16-5a / P16-5s

Holes of this size tend to perform very well with both mid and high frequencies, making this panel especially suitable for dedicated conversation environments. The percentage of perforations is 6.3%.

3- 4for P32-3a / P32-3s

In premises where extensive use of materials such as fabrics and curtains that perfectly absorb high frequencies is expected, this particular perforation is the ideal complement. The percentage of perforations is 0.6%.

4- 4for P32-10a

The essentially flat absorption spectrum at all frequencies gives the designer wide freedom to correct acoustic defects at any
atmosphere. The percentage of perforations is 7.1%.

5- 4for P8-1,2a - Microfor

An effective and elegant technical solution at the same time, with a very dense but aesthetically non-invasive perforation, suitable for the most elegant environments. The percentage of perforations is 1.6%.

The flexibility of the 60×60/120 system resolves acoustic disturbance situations that can occur in different environments such as offices, public spaces or school classrooms, adapting to any layout and use.

Two sizes, three different methods of mounting the elements, multiple drilling schemes, as well as numerous surface finishes, allow the 60×60/120 system to adapt to every architectural situation and functional application. The exterior structure of the building is no longer conceived as a static delimitation element, but as an integrated technological and functional component.

Ceilings and walls .

Ceilings and walls also acquire a series of functions suitable for guaranteeing the comfort and practicality of the premises.


Delivery Time: Consult
Place of Origin: Italy
Shipping Type: Sea and Air (Note: The actual transportation time will be defined at the time of purchase).
